When specifying materials for piping or piling, the choice between Seamless and Welded pipe often dictates the budget and schedule of a project. While both are governed by ASTM standards, their formation creates distinct physical properties.
1. Seamless Pipe (SMLS)
The Process: Seamless pipe is manufactured by heating a solid billet of steel and pushing it over a form (a piercing rod) until the steel is shaped into a hollow tube. There is no welding involved.
- Strength: Generally considered superior for high-pressure containment because there is no weld seam, which is theoretically the "weak point" of a pipe.
- Size Limitations: Typically available only up to 24" or 26" OD. Larger sizes are rare and expensive.
- Common Specs: ASTM A106, API 5L (B through X80).
2. Electric Resistance Welded (ERW)
The Process: ERW pipe starts as a flat sheet of steel (skelp). It is cold-rolled into a cylinder, and the edges are heated and fused together using electric resistance, without filler material. The weld seam is then heat-treated to match the steel's structure.
- Consistency: Because it starts as a flat plate, the wall thickness is often more consistent than seamless pipe.
- Cost: Significantly cheaper to produce than seamless.
- Applications: Structural columns, piling, and low/medium pressure lines.
| Feature | Seamless (SMLS) | Welded (ERW) |
|---|---|---|
| Cost | High | Low / Moderate |
| Pressure Rating | Highest (+20% vs Welded) | Standard (0.85 Joint Factor) |
| Wall Uniformity | Varies (Extrusion process) | Consistent (Rolled plate) |
| Availability | Harder to find > 24" OD | Widely available |
Which should you choose?
For Deep Foundations and structural piling, ERW is the industry standard due to cost efficiency and availability. For High Pressure oil & gas lines or high-temp refineries, Seamless is usually mandatory.
